Excavator extended arm is divided into:

2-phase, three, four stages, extended arms. 2-phase is mainly suitable for sand soil, concrete construction such as transportation, highway slope trimming and river dredging dredging and construction foundation, the river, deep groove conditions such as mining operations, etc.; A three-stage, four-paragraph is mainly suitable for high-rise buildings bringing the dismantling of the assignments, etc.; An extended set of arm: suitable for desilting and berms. Such as installation, disassembly is simple and convenient. Cheap, high efficiency, the excavator extended adaptive extended set of arm extended arm of not more than 4 meters



Working parameters

Model parameters PC200-8 PC220-8 PC300LC - 7 PC360-7 PC400-7 PC450-7

Big lower total length of 15400 mm to 18000 mm 18000 mm to 20000 mm, 22000 mm to 24000 mm

Movable arm length 8300 mm, 10000 mm to 10000 mm, 11000 mm to 12000 mm to 13000 mm

Arm length 7100 mm to 8000 mm 8000 mm to 9000 mm 8000 mm to 11000 mm

Lower total weight 4000 kg, 4600 kg, 5200 kg, 6000 kg, 6500 kg, 7000 kg

Configuration bucket capacity of 0.4 m3 0.4 m3 0.5 m3 0.6 m3 0.6 m3 0.7 m3

Largest mining height 12510 mm to 13500 mm 13500 mm to 14920 mm 13720 mm to 17300 mm

Maximum digging radius 15100 mm to 17300 mm 17600 mm to 19600 mm 19600 mm to 23600 mm

Maximum digging depth 11340 mm to 13000 mm 13200 mm to 15000 mm 15000 mm to 18000 mm

Transport height 2980 mm to 3160 mm 3160 mm to 3210 mm 2980 mm to 3400 mm

Form a complete set of machine weight and configuration

The weight 12 tons of 20 tons, 25 tons of 30 tons of 35 tons 40 tons 45 tons

Extended arm length is 10 meters 18 m 20 m to 22 m 24 m 26 m to 28 m

Extended arm weight of 2.8 tons, 4.8 tons, 2.8 tons of 6.6 tons, 7.5 tons, 6.6 tons of 9.5 tons

Digging bucket capacity of 0.2 0.4 party party party party party 0.8 0.7 0.6 0.5 0.45

Largest mining height of seven meters 15 m 17 m 19 m 21 m 23 m of 25 m

Radius of mining 9 m 17 m 19 m 21 m 23 m 25 m 27 meters

Maximum digging depth 6 meters 14 m 16 m 18 m 20 m 22 meters, 24 meters

Transport 3 meters 2.2 meters 3.2 meters 3.2 meters 3.2 meters 3.2 meters 3.2 meters

Extended arm a full set of configuration:

Contains: (a) a two-part extended arm extended arm (1), elongated forearm (1), scoop (1), bucket cylinder (1), pin (6), high pressure hose (4), butter tube (3), connecting rod assembly (1);

Contains: (2) a three-stage extended arm extended arm (1), (1), extended the arm extended forearm (1), scoop (1), bucket cylinder (1), pin (11), high pressure hose (24), butter tube (12), connecting rod assembly (1 set), weight (2-3 tons);

(3) the four-paragraph extended arm includes: extended arm (1), (1), extended the arm extended forearm (2), scoop (1), bucket cylinder (2), pin (16), high pressure hose (28), butter tube (14), connecting rod assembly (2 sets), weight (3-5 tons).
